Products

Traction type

6×4

Drive System

LHD

Cabin

V3 Flat Cabin, Air Conditioner ,one sleeper

Engine

Brand

WEICHAI

Model

WP10.380E32  EGR

Rated power

380hp

Engine displacement

9.726 liters

Gearbox

FAST 9 Speeds (9JS150A)

Clutch

Ф430 Diaphragm type

Steering

ZJ120D/ZF8098

Axle

Front

BEIEBN 7.5 Ton

Rear

BEIBEN 13 Ton double reduction axle, ratio:5.921

Max. running speed (km/h)

85

Tire

12.00R20

Spring

10/13

Fuel tank

300L

Kerb weight (kg)

12300

Total mass (kg)

25000

Wheel base (mm)

3450+1450

Overhang (mm) (front/rear)

1515/1705

Track (mm) (front/rear)

1995/1800

Approach / departure angle(°)

23/33

DimensionsL*W*H(mm)

Overall

8120x2500x3430

Dump body

5400x2300x1500(18.6m3)

Thickness (mm)

Bottom 8 , front 6mm,side 4

Hydraulic lifting system

  Middle lifting
