Traction type | 6X4 | |||
Driving type | LHD/RHD | |||
Dimension(Lx W xH)（unloaded） | 10576×2500×3430 | |||
Wheel base(mm) | 5050+1450 | |||
Max speed（km/h） | 90 | |||
Curb weight（kg） | 12000 | |||
Loading Weight（kg） | 25,000 | |||
Engine Steyr technology, made in China | Model:WD615.340 | water-cooled，four strokes，6 cylinders in line，turbocharged, directly injection With the exhaust valve brake, EGR (gas exhausted recycling), deisel engine | ||
Displacement（L） | 9.726/Diesel | |||
Bore X stroke(mm) | 126/130 | |||
Max power（kw/rpm） | 247/2200 (340hp) | |||
Max torque（Nm/rpm） | 1350/1300-1600 | |||
Emission | EURO II | |||
Fuel tanker（L） | 400L steel fuel tanker | |||
Clutch | Model | 430 Diaphragm type | ||
Gearbox | Model | 9JS150 (Fuller) mechanism, 9gears, 1reverse gear | ||
Brake system | Service brake | Brake gap can be adjusted automatically, double circulation air brake system | ||
Assistant brake | Engine exhaust brake | |||
Park brake | Potential springs pressing on middle and rear wheels | |||
Steering system | Model | ZF8098 | ||
Frame | Fish belly, shape, variable width, variable sections, side beam structure | |||
Front axle (Mercedes Benz Technology) | 7.5T Double-shoe pneumatic brake, non-driving steering axle
| |||
Middle and Rear axle (Mercedes Benz Technology) | 13T Double-shoe pneumatic brake, casting, double reduction driving axles with inter-wheel & inter-axles differential locks
| |||
Tyre | 12.00R20 Radial tyre Number of tyre:10+1 spare | |||
Electrical system | Battery | 2X12V/135Ah | ||
Generator | 28V-35A | |||
Starter | 5.4Kw/24V | |||
Cab | Mercedes-Benz technology NG80B long Cabin, single sleeper with air-conditioner Full steel skeleton structure, covered with double layer steel plate; Can be tipped forwardly; | |||
Water tank | ||||
Tank capacity | 18,000 liters | |||
Thickness of the tanker body | the thickness of the shell is 5mm approx; | |||
Dish ends | the thickness of the shell is 6mm approx; | |||
