Main Frame

Heavy duty and extra durability designed; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes.

Axle

13T

Suspension

mechanical suspension

Leaf Spring

Four sets reliable local brand, 8-piece leaf spring, 16*90mm

King Pin

2inch or 3.5inch

Landing Gear

Two-speed, manual operation, heavy duty 28t

Wheel Rim

9.25-22.5 rim

Tire

12R22.5 tire

Twist Lock

12nos.

Spare Wheel Carrier

One set of spare wheel carrier including a riser.

Pneumatic Braking System

One units of WABCO RE 4 relay valve; four units of T30/30 spring brake chamber; one unit of reliable local brand 45L air tank; two units of reliable local brand standard coppery air-connector.

Electrical System

One unit of JAEGER POWAY, 24V 7-pin ISO 1185 socket; two sets of reliable, local brand standard rear light, turn light, rear reflector, side light, side reflector etc. One set of DAFA(brand) 6-core standard Cable.

Painting

Sand blasting before painting; one coats of primer, anti corrosion;

two coat of finish painting; color advised by client.

Accessory

One box with a set of standard trailer tool


Terms and Conditions :


1. This quotation will serve as base of our later P/I or contract.

2. Lead Time:  **days after downpayment reaches the seller(adjusted by the quantity and model).

3. Payment Terms: T/T 30% before SOP(Start Of Production), and T/T 70% balance before shipment.

4.Expiry date: This quotation valid for one week only.

5.This offer is subjected to seller's final confirmation .

7. Quality level: excellent quality for international market, made in China, WONDEE brand

8. Certificate: ISO9001; TS16949; COC; PVOC; CIQ; SONCAP; BV; C/O; FORME.

9. Area suitable: America,Europe,Asia
