Products

Traction type

6x4

Drive System

LHD

Cabin

V3 Flat Cabin, Air Conditioner ,one sleeper

Engine

Brand

WEICHAI

Model

Weichai 340

Rated power

340hp

Engine displacement

9.726 liters

Gearbox

FAST 12 Speeds (12JS160T)

Clutch

Ф430 Diaphragm type

Steering

ZJ120D

Axle

Front

BEIEBN 7.5 Ton

Rear

BEIBEN 13 Ton double reduction axle, ratio:5.921

Max. running speed (km/h)

85

Tire

12.00R20

Spring

10/13

Fuel tank

300L

Kerb weight (kg)

12300

Total mass (kg)

25000

Wheel base (mm)

3450+1450

Overhang (mm) (front/rear)

1515/1705

Track (mm) (front/rear)

1995/1800

Approach / departure angle(°)

23/33

DimensionsL*W*H(mm)

Overall

8320x2500x3430

Dump body

5600x2300x1500

Thickness (mm)

Bottom 8 , front 6mm,side 4

Hydraulic lifting system

  Middle lifting
